Which Artwork File Formats Work for Custom Patches? (AI, EPS, PDF, PNG)

The most useful patch artwork file formats are AI, EPS and PDF containing vector shapes; PNG can also work if it shows the design clearly at the intended size. For a logo, send the original vector file if available, rather than a screenshot or an image copied from a website.

A low-resolution logo is still worth sending for assessment, but it may not contain enough information to reproduce fine lettering or symbols accurately. Include your intended dimensions and patch type: a file that suits a printed patch may need simplification for embroidery.

Which patch artwork file formats should you send?

Vector artwork describes shapes using paths rather than a fixed grid of pixels. It can be enlarged without pixelation, making it useful for checking outlines, adjusting lettering and separating colour areas.

Raster artwork, including PNG, stores pixels. AI, EPS and PDF can contain raster images too, so saving a blurry logo inside a PDF does not make it vector artwork.

How much resolution does a PNG need?

For printed artwork, 300 pixels per inch at finished size is a useful starting point, not a universal requirement. A patch 75 mm (2.95 inches) wide would need roughly 886 pixels across at that resolution; sharp source edges still matter.

Changing a file's DPI setting without adding genuine image detail does not improve it. For embroidery, readable shapes matter more than a particular resolution label, because the design must be interpreted as stitches.

Will a perfect vector file make every detail work?

No. Vector quality removes pixelation, but it does not remove the physical limits of thread. Small lettering can fill in, narrow gaps can close, and fine outlines may merge on embroidered patches.

• Choose embroidery for bold shapes, clear lettering and visible thread texture.
• Consider woven patches for finer lettering and linework with a flatter textile surface; these still have detail limits.
• Consider printed patches for photographs, gradients or complex tonal detail.
• Increase the patch size or simplify the design if small text must remain readable.

Judge the design at its intended physical size, not only enlarged on screen. Best Fonts for Patch Lettering: Readability at Small Sizes explains lettering choices; Can You Put a Photo or Gradient on a Patch? Printed and Sublimated Options covers tonal artwork.

What can a patch maker do with a low-resolution logo?

A small PNG or screenshot can show the overall layout, colours and wording. A patch maker may be able to reconstruct simple shapes from it, but missing detail cannot be recovered reliably just by enlarging the image.

Automatic tracing can turn pixels into vector paths, yet it may also copy jagged edges and distort letters. Redrawing requires interpretation, so do not assume artwork reconstruction is included, free or possible for every image; ask what preparation is needed.

• Look for the original file from your designer, club secretary or brand asset folder.
• Send the uncropped original rather than a screenshot inside a document.
• Type any small or unclear wording separately, including punctuation.
• Identify details that must stay unchanged and those that may be simplified.
• Provide a colour reference if available; screen colours alone are not a physical colour standard.

How should you prepare and send the artwork?

Use our quote form to submit your artwork and specification together. An isolated logo does not tell us the finished size, quantity or garment, and those details affect the practical design choices.

1. Choose the best source file. Prefer original vector artwork; otherwise send the highest-quality raster original available.
2. Prepare a sharing copy. For vector artwork, convert text to outlines and embed linked images, while retaining your editable master.
3. State width and height in millimetres, with the intended shape and border. Make clear whether dimensions include the border.
4. Give the quantity per design and preferred patch type. Our minimum is 5 pieces per design.
5. Name the garment and backing preference, such as sew-on for a canvas cap or a backing to assess for a nylon shell.
6. Include exact wording, colour references, any required delivery date and a clearly identified current artwork version.

Keep technical notes outside the patch outline so they are not mistaken for part of the design. For waterproof clothing, read Patches on Waterproof Jackets: How to Add One Without Leaks before specifying attachment.

What should you approve before production?

At The Customized Patches, the digital mockup is free and usually provided within 12 hours. We make patches to order from your artwork and produce only after approval; the mockup turnaround is not a production or delivery promise.

• Check spelling, punctuation and the correct artwork version.
• Confirm finished dimensions, shape, border and backing.
• Review any simplified lettering, removed detail or adjusted spacing.
• Confirm colour references and ask about colour-matching limits.
• Check quantity per design and the quoted production and delivery schedule.

A digital mockup shows the proposed appearance, not an exact physical preview of thread texture or colour. Quotes start from £60 and shipping is free across the United Kingdom; ask for a quote for your specification and confirm timing before relying on an event deadline.
